Hanwha Techwin AFF-QNP-6230RH Overview
Monitor an indoor or outdoor area with the AFF-QNP-6230RH 2MP PTZ Network Camera from Hikvision. This unit uses a 1/2.8" CMOS sensor to capture 1920 x 1080 resolution video at 30 fps. IR LEDs provide up to 328' of night vision. A 4.44-102.2mm varifocal lens delivers a 61.8 to 3.08° horizontal field of view. This camera features endless panning, a -5 to 90° tilt range, and 23x optical zoom. A built-in memory card slot accepts microSD/SDHC/SDXC cards up to 256GB (available separately). Two-way audio is possible thanks to an audio input and output. Integrated PoE technology simplifies connectivity by transferring data and power over one cable.
- 2MP (1920 x 1080) resolution
- H.265, H.264, MJPEG codec support
- Multiple streaming, WiseStream II support
- IR range for up to 328ft
- Day & Night (ICR), WDR (120dB)
- DIS with Built-in Gyro sensor
- Tampering, Motion detection
- Memory slot (Max. 256GB)
- IP66, IK10, IK10
- 24VAC / HPoE, Built-in -58?F (-50?C) Heater (24VAC only)
This NDAA-compliant PTZ camera complies with ONVIF profiles G, S, and T, making it compatible with a wide range of surveillance devices. It is housed in an IP66- and IK10-rated enclosure that is suitable for safe outdoor use in areas at risk of vandalism.
- IR cut filter for day and night functionality
- H.265, H.264, and MJPEG video codecs
- WiseStream II support
- Unicast and multicast streaming
- Up to ten users in unicast mode
- CBR and VBR
- Electronic shutter speed
- DC auto iris
- Digital image stabilization with built-in gyro sensor
- 4.92' wide and 6.56' tele minimum object distance
- BLC, HLC, 120 dB WDR, and SSDR
- Digital noise reduction (SSNR V)
- Gain control
- Defogging
- Adjustable white balance
- Privacy masking for up to six rectangular zones
- Flip and mirror video rotation
- 100M Ethernet port
- Audio input and output
- 4 x alarm inputs and 2 x alarm outputs
- CVBS video output
- RS-485 port with support for Samsung-T, Pelco D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell protocols
- Analytics include; directional detection, motion detection (8 polygonal zones), enter/exit, tampering, and virtual line
- Alarm triggers include; analytics, network disconnect, and alarm input
- Alarm events include; file upload via FTP and email, notification via email, microSD or NAS recording at event triggers, alarm output, and PTZ preset
- Supported browsers include; Internet Explorer 11, Edge, Firefox (Windows 64-bit), Safari (Mac OS X)
- Endless panning
- 0.024 to 250°/s manual pan speed
- 400°/s preset pan speed
- -5 to 90° tilt range
- 0.024 to 250°/s manual tilt speed
- 250°/s preset tilt speed
- 23x optical zoom
- 300 presets
- Swing, group (6), trace, tour, auto run, and schedule sequence
- ±0.2°
- Azimuth support
Wisenet Q network outdoor IR PTZ camera, IR range for up to 328ft, 2MP, Full HD(1080p) 30fps, triple codec H.265/H.264/MJPEG with WiseStream II, 23x optical zoom (4.44 ~ 102.2mm) (61.8º ~ 3.08º), 120dB WDR, HLC, true D/N, 24VAC / HPoE, IP66, IK10, Built-in -58°F (-50°C) Heater (24VAC only)
Key Features- 1920 x 1080 Resolution at 30 fps
- IR LEDs for Night Vision up to 328'
- 4.44-102.2mm Varifocal Lens
- 61.8 to 3.08° FOV & 23x Optical Zoom
- Endless Panning & -5 to 90° Tilt Range
- Two-Way Audio
- Supports microSD Cards up to 256GB
- Complies with ONVIF Profiles G, S & T
- IP66 Rated for Outdoor Use
- IK10-Rated Vandal Resistance
