Key Features
- ONVIF protocol support
- HDMI output
- Audio in/out
- Max. 4MP resolution
- Max. 15fps @4MP, 30fps @1080p
- H.264, MJPEG codec support
- Multiple streaming (up to 3 profiles per channel)
- 10/100/1000 Base-T
- Supports AHD, CVI, TVI, & CVBS video formats
- Supports ACP/Pelco-C up-the-coax & RS-485/422 PTZ control interface
- Motion detection, Video loss, Tampering
- H.264, MJPEG codec support
- ECO. Stream. bandwidth reduction technology per channel/profile (firmware v1.04b_200227 / v1.30+ only)
- Multiple streaming (Up to 3 profiles per channel)
- HDMI Output
- Alarm & Audio I/O
Encoder, 16CH H.264/MJPEG, 30fps @ 2MP or lower and 15 fps @ 4MP, AHD/CVI/TVI/CVBS compatible, RS-485/422 Interface, Pelco C when using CVBS or ACP up-coax protocol @ AHD, ONVIF protocol support, HDMI output, I/O 16/4, Audio in/out 4/1, 12VDC
